RCF L-PAD 8C LivePad

Name: RCF L-PAD 8C LivePad
Brand: RCF
SKU: 357512
Price: 128.16 EUR
Availability: OutOfStock

8-channel compact mixing console, featuring 4 mono and 3 stereo channels. Ideal for small to medium-sized setups, this mixer is perfect for live performances, recording, and more. Get professional sound quality and versatility in a compact package.

Brand: RCF | Code: 357512

128,16 €

152,51 € with VAT

● Currently sold out

RCF - L-PAD 8C LivePad • 8-channel mixing console • 2 (4 mic) mono + 3 stereo IN • 2 compressors (channels 1 and 2) • 3-band/2-band EQ • 1 AUX send • dimensions: 384 x 250 x 80 (mm) • weight: 2.3 kg

LivePad is a new line of compact and flexible mixing consoles from the Italian manufacturer RCF.

Since 1949, the Italian company RCF has been producing speakers for the most renowned manufacturers of speaker cabinets worldwide. For over 30 years, they have been manufacturing their own professional speaker cabinets, which have become a standard in a wide range of professional applications, from solo performances to massive rock concerts. The RCF brand is also represented in thousands of fixed installations around the world, such as stadiums, train stations, airports, office buildings, amusement parks, etc., where RCF amplifiers, signal processors, and distributors are often used.

By leveraging all their experience and aiming to make their offering even more comprehensive, RCF has introduced the new range of LivePad mixing consoles.

The attractiveness of these essential tools for live sound reinforcement, whether it's a rock band or a jazz quartet concert, a conference, or multimedia center sound reinforcement, is enhanced by the elegant and modern Italian design.

The L-PAD series includes 9 models: L-PAD 6, 6X, 8C, 8CX, 10C, 12C, 12CX, 16CX-USB, and 24CX-USB, where the number indicates the number of channels. All models are characterized by uncompromising sound quality, with the three "X" models featuring an effects module integrated, and the "C" models including a compressor on each microphone channel with very responsive threshold and compression ratio adjustment through a single control. All models feature a 3-band EQ on each mono channel and a 2-band EQ on each stereo channel. The 16CX and 24CX are additionally equipped with a USB port on the rear panel for easy connection to any computer. Any operating system recognizes the L-PAD mixing console as an audio device for recording and playback purposes.

In line with their sound culture philosophy, RCF has paid exceptional attention to the design of all electronic circuits to achieve clean and musically pleasing sound, high-quality and precise dynamic response, combined with exceptional flexibility of use. Models 8C, 8CX, and 10C feature 45mm faders, while models 12C, 12CX, 16CX-USB, and 24CX-USB feature 60mm faders. The advanced internal DSP includes 16 preset effects for the 6CX model and 99 presets for the 8CX, 12CX, 16CX, and 24CX models. During the development of the LivePad mixers, great attention was also paid to the optimal interaction with RCF's range of active speaker cabinets, such as ART, 4Pro, NX, or D-Line. To ensure maximum reliability, the consoles undergo multiple tests during production for all functions and sound quality, including output listening tests and visual inspections.

The LivePad consoles are suitable for any application and allow for expansion for playing and recording MP3 music files, which can then be saved on a USB storage device with a capacity of up to 32 GB. The Bluetooth adapter enables wireless connection of additional devices, such as smartphones, tablets, and computers, to the mixer, allowing music playback directly into the console without the need for additional wiring.

Accessories: LIVEPAD Player Card, LIVEPAD Player/Recorder Card, LIVEPAD Bluetooth Card

Specifications:


Mono channels
Microphone input	XLR balanced
Frequency response	10Hz to 55kHz,+/-3dB
Distortion(THD+N)	<0.03% at +0dB ,22Hz~22kHz A-weighted
Gain range	0dB to -50dB
Max. input	+15 dB
LOW CUT	75Hz
SNR	<-100dBr A-weighted
Phantom power	+48V with switch control
Line input	1/4’ TRS balanced
Frequency response	10Hz to 55kHz,+/-3dB
Distortion(THD+N)	<0.03% at +0dB ,22Hz~22kHz A-weighted
Sensitivity range	+15dB~ -35dB
Compressor	GAIN: 0 to 9dB, THRESHOLD: 20 to 5dB
Stereo input channels
Mic input	XLR balanced
LOW CUT	75Hz
Line input	1/4’ TRS or TRS/RCA un-balanced
Frequency response	10Hz to 55kHz,+/-3dB
Distortion(THD+N)	<0.03% at +0dB ,22Hz~22kHz A-weighted
Sensitivity range	-15dBu~ +35dBu
SNR	<-100dBr A-weighted
Channels EQ	Mono channel; Stereo channel
High	+/-15dB @12KHz; +/-15dB @12KHz
Mid	+/-15dB @2.5Hz; N/A
Low	+/-15dB @80Hz; +/-15dB @80Hz
2-TRACK IN
TAPE IN	RCA jack
Frequency Response	10Hz to 55kHz,+/-3dB
Distortion (THD+N)	<0.03% at +0dB ,22Hz~22kHz A-weighted
Gain Range	OFF to 0dB
STEREO RETURN
Input	1/4’ TRS un-balanced
Frequency response	10Hz to 55kHz,+/-3dB
Distortion(THD+N)	<0.03% at +0dB ,22Hz~22kHz A-weighted
GAIN range	OFF TO +10dB
SNR	<-100dBr A-weighted
Impedances
Microphone input	1.8 kOhm
All other input	10 kOhm or greater
Tape out	1 kOhm
All other out	120 Ohm
Main mix section
Max. MAIN MIX output	+22dBu un-balanced
AUX range	OFF to +10dB
Fader range	OFF to +10dB
PHONES/CONTROL-ROOM range	OFF to +10dB
Hum & Noise	<-80dB @ 20Hz~22kHz A-weighted 1 channel & MAIN
	level:0dB,the other :minimum
Crosstalk	<-80dB @0dB 20Hz~22kHz A-weighted MAIN
	level:0dB,the other :minimum
Power supply
AC adaptor 18VAC	1000mA
Power consumption	24W(all loaded)
Dimensions	L=384mm, W=250mm, H=80mm
Weight	2,300 kg
