EAW QX564i

Name: EAW QX564i
Brand: EAW
SKU: 352791
Price: 5591.49 EUR
Availability: OutOfStock

Passive full-range speaker, power: LF 2000/4000 W / 2 ohm (2x1000/2000 W / 4 ohm), MF/HF 175/350 W / 8 ohm, configuration: 4 x 12" + Coaxial 2", dispersion angle: 60° x 45°, weight: 61 kg.

Brand: EAW | Code: 352791

5.591,49 €

6.653,87 € with VAT

● Currently sold out

EAW – QX544i • 3-way passive full-range • bi-amp • LF 2000/4000 W / 2 ohm (2x1000/2000 W / 4 ohm), MF/HF 175/350 W / 8 ohm, 1000 W / 4 ohm • LF 4 x 12" + MF 1 x 2" exit with 3.5" diaphragm + HF 1 x 2" exit 1.75" coil • frequency range -10 dB: 55 - 20000 Hz • max SPL: 142 dB • trapezoidal enclosure • coverage angle: 60 x 45° • 710 x 710 x 605 x 403 (mm) • 61 kg Revealing the new EAW QX500 series loudspeakers, these units deliver powerful performance suitable for long-distance sound reinforcement in arenas, stadiums, live concerts, or dance clubs where high volume is essential. Balanced sound dispersion is ensured across the frequency range and declared coverage angle even in challenging listening environments like churches or public spaces prone to reflections. Exceptional fidelity in reproduction satisfies even the most discerning audiences in concert halls and theaters. The 3-way loudspeakers feature a trapezoidal enclosure and utilize a unique ultra-powerful compression driver. The model numbers in the QX5xx series with coverage angles of 45x45°, 60x45°, 60x60°, and 90x60° indicate the horizontal and vertical angles respectively. Four 12" low-frequency drivers are symmetrically placed around coaxially arranged HF & MF drivers, simulating a single point source for the entire frequency spectrum. This ideal sound coherence is maintained across both horizontal and vertical angles.

Warranty 72

Weight 61

This product has no downloads.
