Allen & Heath - XONE:43C

• 4+1 channel DJ mixer with integrated USB sound interface
• 16-channel sound interface, 96kHz / 24bit
• Compatible with Serato DJ and Serato DVS Upgrade ready (paid upgrade)
• X:LINK protocol for connecting Xone:K series controllers
• 4x phono / USB / line inputs
• VCF Filter system – voltage-controlled low, high, and bandpass filters with frequency and resonance control
• Three-band EQ
• External effect loop system (Send/Return) with dry/wet control on each channel
• Microphone input with balanced XLR connector and dual-band EQ
• Balanced XLR master output
• Independent monitor booth output
• Record out
• 3.5mm and 1/4” headphone outputs
• Robust touring construction
• Channels equipped with smooth VCA faders
• Accessible crossfader for user-friendly disassembly
• Compatible with Innofader
• Switchable crossfader curve settings
• +20 dB professional headroom
• 9-segment LED level meter for output level monitoring
• Dimensions: 320 x 110 x 370 mm
• Weight: 5.2 kg

4+1 Channel DJ Mixer with Sound Interface

Xone:43C provides a comprehensive view into the vast world of digital DJing, which has been defined in recent years by the leading software platform Serato DJ. The option for DVS upgrade using Serato Club Kit for integration with supported mixers eliminates the need for users to use any external devices, creating a versatile environment for a smooth and unique mixing experience.

Xone:43C is a 4 + 1 channel mixer with intuitive ergonomics and excellent sound quality, equipped with the legendary Xone filter, three-band EQ, X:FX effect loop for integrating external effects with individual send/return control for each channel. With separate buses for external effects and internal VCF, the filter can be placed before the effect loop or used to filter an already affected signal from an external device. Xone:43C also features a top-notch 16-channel sound interface for digital DJ setups and plug-and-play X:Link protocol for expanding MIDI control elements.

Three selectable crossfader curve types for transitions and turntablist techniques allow for a unique expression for all types of users. The device allows for swapping with a special Innofader for uncompromising performance.

For integration in clubs and DJ setups, Xone:43C features a high-quality balanced XLR master output and separate booth and record outputs.

Serato DVS Compatibility

Xone:43C is a convenient way to use Serato NoiseMap™ technology for Vinyl and CD for direct control over Serato DJ software. New users can easily purchase the Serato DJ Club Kit, available in-app with Serato DJ software in the Serato online store. The mixer does not support control of Serato Video faders.

Premium Integrated Sound Card

The sound interface integrated in the mixer features 16 channels with a sampling frequency of 96 kHz and a depth of 24 bits, allowing for easy integration into any DJ setup.

X:Link

For an unbeatably modular DJ setup, simply connect Xone:K controllers via X:Link protocol to the Xone:43C mixer, providing easy access to Serato DJ software functions. The script for mapping key controls ensures easy programming of the controller for channels 1 to 4.
